IMPORTANT: VMware has ended active development of this project, this repository will no longer be updated.

NOTE: This is the knative branch of Dispatch. Full Dispatch functionality is still a ways off. The code here
represents a work in progress. For information about Dispatch Solo, the version of Dispatch distributed as an OVA,
see the solo branch or documentation.

Dispatch is a framework for deploying and managing serverless style applications. The intent is a framework
which enables developers to build applications which are defined by functions which handle business logic and services
which provide all other functionality:

State (Databases)
Messaging/Eventing (Queues)
Ingress (Api-Gateways)
Etc.

Our goal is to provide a substrate which can be built upon and extended to serve as a framework for serverless
applications. Additionally, the framework must provide tools and features which aid the developer in building,
debugging and maintaining their serverless application.

Documentation

Checkout the detailed documentation including a quickstart guide.

Architecture

NOTE: The information in this section is specific to the knative branch of Dispatch. Equivalent documentation for Dispatch Solo can be found on the solo branch.

The diagram below illustrates the different components which make up the Dispatch project:

initial dispatch architecture diagram

Installation

NOTE: The information in this section is specific to the knative branch of Dispatch. Equivalent documentation for Dispatch Solo can be found on the solo branch.

Prerequisites

GKE

Create service account key

bash
export GCLOUD_KEY=<path to key.json>

Create GKE cluster:

bash
K8S_VERSION=1.10.7-gke.6
export CLUSTER_NAME=dispatch-knative
gcloud container clusters create -m n1-standard-4 --cluster-version ${K8S_VERSION} ${CLUSTER_NAME}
gcloud container clusters get-credentials ${CLUSTER_NAME}

Install Knative:

bash
# Get the current knative verision used with dispatch
KNATIVE_VERSION=$(cat Gopkg.toml | grep -A 2 'name = "github.com/knative/serving"' | grep revision | cut -d '"' -f2)
./scripts/install-knative.py ${CLUSTER_NAME} --gcloud-key=${GCLOUD_KEY} --revision=${KNATIVE_VERSION}

VMware Cloud PKS

Create a Cloud PKS cluster with privileged mode enabled.

bash
export VKE_CLUSTER=dispatch-knative
vke cluster create --privilegedMode  --name $VKE_CLUSTER  --cluster-type PRODUCTION --region us-west-2

Get kubectl credentials:

bash
vke cluster auth setup $VKE_CLUSTER

Install Knative:

Install Istio:

bash
kubectl apply -f third-party/vmware-cloud-pks/istio-1.0.2/istio.yaml

Wait for Istio pods to become READY (will take a little while to scale up smart cluster):

bash
kubectl get pods -n istio-system
NAME                                        READY     STATUS      RESTARTS   AGE
istio-citadel-746c765786-2cm5p              1/1       Running     0          6m
istio-cleanup-secrets-vbqk7                 0/1       Completed   0          6m
istio-egressgateway-57df84cfcf-hpkx4        1/1       Running     0          6m
istio-galley-5b4f774c-9gcqm                 1/1       Running     0          6m
istio-ingressgateway-76dbd65c-7qf2w         1/1       Running     0          6m
istio-pilot-7ddfbdf465-cj5jl                2/2       Running     0          6m
istio-policy-56789fbb8c-flxkz               2/2       Running     0          6m
istio-statsd-prom-bridge-7c77ddc9b9-s2zwl   1/1       Running     0          6m
istio-telemetry-855bb88878-kbhsj

Install Knative serving (includes build):

bash
kubectl apply -f third-party/vmware-cloud-pks/serving-0.2.2/release.yaml

Other

In order to install Knative, follow the development instructions

Dispatch

Installing Dispatch depends on having a Kubernetes cluster with the Knative components installed (Build, Serving and soon Eventing). From here build and install dispatch as follows:

Set the following environment variables:

bash
export DISPATCH_NAMESPACE="default"
export DISPATCH_DEBUG="true"
export RELEASE_NAME="dispatch"
export MINIO_USERNAME="dispatch"
export MINIO_PASSWORD="dispatch"
export INGRESS_IP=$(kubectl get service -n istio-system knative-ingressgateway -o wide | tail -n1 | awk '{print $4}')

Build and publish a dispatch image (Substitute in your docker repository):
Note: if you just want to use a pre-created image use the script to create your values.yaml and continue to step 4.
```
bash
TAG="v0.1.22-knative" ./scripts/values.sh
```
```
bash
DISPATCH_SERVER_DOCKER_REPOSITORY=<docker repository username> PUSH_IMAGES=1 make images
```

The previous command will output a configuration file values.yaml:

yaml
image:
  host: username
  tag: v0.1.xx
registry:
  url: http://dispatch-docker-registry:5000/
  repository: dispatch-docker-registry:5000
storage:
  minio:
    address: dispatch-minio:9000
    username: ********
    password: ********

Deploy via helm chart (if helm is not installed and initialized, do that first):

bash
helm init --wait
# helm won't overwrite the existing config-maps (at least not the first/install time), so explicitly delete them.
kubectl delete configmap -n knative-serving config-domain config-network
helm dependency build ./charts/dispatch/
helm upgrade -i --debug ${RELEASE_NAME} ./charts/dispatch --namespace ${DISPATCH_NAMESPACE} -f values.yaml

NOTE: Use following to create cluster role binding for tiller:
bash
kubectl create clusterrolebinding tiller-cluster-admin --clusterrole=cluster-admin --serviceaccount=kube-system:default

Reconfigure Knative serving (need to whitelist our internal repository):
```
bash
./scripts/configure-knative.sh
```

Build the CLI (substitute darwin for linux if needed):

bash
make cli-darwin
# Create symlink to binary
ln -s `pwd`/bin/dispatch-darwin /usr/local/bin/dispatch

Create the Dispatch config:

bash
cat << EOF > config.json
{
  "current": "${RELEASE_NAME}",
  "contexts": {
    "${RELEASE_NAME}": {
      "host": "$(kubectl -n ${DISPATCH_NAMESPACE} get service ${RELEASE_NAME}-nginx-ingress-controller -o wide | tail -n1 | awk '{print $4}')",
      "port": 443,
      "scheme": "https",
      "insecure": true
    }
  }
}
EOF
# point to the config file (could also move to ~/.dispatch/config)
export DISPATCH_CONFIG=`pwd`/config.json

Test out your install:
First, create an baseimage:

bash
dispatch create base-image python3-base dispatchframework/python3-base:0.0.13-knative
Created baseimage: python3-base

Then, create an image:

bash
dispatch create image python3 python3-base
Created image: python3

Wait for status READY:

bash
dispatch get images
   NAME  | DESTINATION | BASEIMAGE | STATUS |         CREATED DATE
--------------------------------------------------------------------------
 python3 | *********** | ********* | READY  | Tue Sep 25 16:51:35 PDT 2018

Create a function:

bash
dispatch create function --image python3 hello ./examples/python3/hello.py
Created function: hello

Once status is READY:

bash
dispatch get function
   NAME  | FUNCTIONIMAGE | STATUS |         CREATED DATE
----------------------------------------------------------------
  hello  | ************* | READY  | Thu Sep 13 12:41:07 PDT 2018

Exec the function:

bash
dispatch exec hello <<< '{"name": "user"}' | jq .
{
  "context": {
    "logs": {
      "stdout": [
        "messages to stdout show up in logs"
      ],
      "stderr": null
    }
  },
  "payload": {
    "myField": "Hello, user from Nowhere"
  }
}

Create an endpoint:

bash
dispatch create endpoint get-hello hello --method GET --method POST --path /hello

Hit the endpoint with curl:

bash
curl -v http://${INGRESS_IP}/hello?name=Jon -H 'Host: default.${DISPATCH_NAMESPACE}.dispatch.local'

For a more complete quickstart see the developer documentation
